Engine Power - Net 52 kW Engine Model Cat C3.6* 55 kW Electronic Turbo Intercooled Displacement 3.6 l Torque Rise - 1,200 rpm - Net 86% Bore 98 mm Stroke 120 mm Note *Meets India Bharat Stage V emission standards. Ratings @ 2,200 rpm - Gross Power ISO 14396 55 kW/74 hp/75 mhp Ratings @ 2,200 rpm - Gross Power SAE J1995 56 kW/75 hp/76 mhp Net Power Rating @ 2,200 rpm - ISO 9249 51 kW/69 hp/70 mhp Net Power Rating @ 2,200 rpm - SAE J1349 52 kW/70 hp/71 mhp Weights Operating Weight - Nominal 7980 kg Operating Weight - Maximum 8760 kg Air Conditioning 45 kg Total Gross Weight Not to Exceed 8760 kg Counterweights - Base 115 kg Cab - ROPS/FOPS 118 kg Counterweights - Maximum 300 kg Note Machine configuration: standard engine, standard stick hoe, standard cab with air conditioning, 2WD, 1.05 m³ GP loader bucket, 0.27 m³ standard duty hoe bucket, industrial tire, 115 kg counterweight, 80 kg operator, full fuel tank. Operating Weight - Maximum - ROPS Capacity 19312 lb Hydraulic System System Pressure - Loader 245 bar System Pressure - Backhoe 245 bar Type Closed Center Pump Type Variable-Flow, Axial Piston Pump Capacity @ 2,200 rpm 132 l/min Steering Turning Circle (inner wheel not braked) - Outside Widest Loader Bucket 12.2 m Type Front Wheel Power Steering Hydrostatic Turning Circle - (inner wheel not braked) - Outside Front Wheels 9.3 m 2WD Cylinder, One (1) Double Acting - Bore 75 mm 2WD Cylinder, One (1) Double Acting - Axle Oscillation 9 ° 2WD Cylinder, One (1) Double Acting - Stroke 118 mm Turning Circle 2WD 2WD Cylinder, One (1) Double Acting - Rod Diameter 45 mm Bezichting op afspraak Nee Merk: Cat Type: 424 Merk motor: Cat Brandstof: Diesel Bedrijfsgewicht: 7980kg Cabine: true Afgelezen urenstand: 1 Eigen gewicht: 7980kg... lees meer
