Elektro automatik - psi 9040-120 3000w - labvoeding

Specification EA-PSI 9040-120 2U Output voltage 0–40 V DC Output current 0–120 A Max. output power 3000 W AC input 180–264 V AC, 1-phase Frequency 45–65 Hz Efficiency up to 92% Power factor 0.99 Voltage accuracy 0.1% of nominal Current accuracy 0.2% of nominal Voltage load regulation 0.05% Current load regulation 0.15% Voltage ripple 114 mVpp / 8 mVrms Current ripple 11 mArms OVP range 0–44 V OCP range 0–132 A OPP range 0–3300 W Remote sensing Yes Analog control Isolated, 0–5/0–10 V USB Yes Rack size 19", 2U Dimensions approx. 483 × 88 × 463 mm Weight approx. 15 kg Operating temperature 0–50 °C Nee Merk: Elektro Automatik Type: PSI 9040-120 3000W
